The boiler is composed of furnace, water supply, self-control, heating and safety protection system. It uses electricity to generate heat and generate steam with a certain pressure. It has the characteristics of convenient use, simple operation, economical and wide application fields.
Rated thermal power: 0.5-4.0 t/h
Rated thermal efficiency: 98%
Pressure: ≤1.25MPa
Available fuel: electric energy
The boiler has no combustion chamber, no chimney, no need to consider heat loss, and the thermal efficiency is above 98%.
Adopt scientific and reasonable design structure and advanced manufacturing process to reduce boiler space and save the use of the site.
The boiler has multiple protections such as voltage, water level, power supply and pressure, which is safe and reliable.
The boiler operation period can be set as required, and each heating group can be automatically time-divisionally activated to extend the service life of the equipment.
The control system monitors the ion concentration in the water in real time. When the concentration exceeds the limit value, the discharge solenoid valve opens automatically to realize automatic discharge. At the same time, the pump starts to re-inject pure water to avoid scaling on the heating surface.
The unique patented scale alarm technology monitors the formation of scale on the heated surface in real time. Once the scaling on the heating surface is found to exceed the standard, the alarm system will be activated immediately.
| Types | Evaporation | Steam pressure | Steam pressure | Thermal efficiency | Fuel | Length*Width*Height | Weight |
|---|---|---|---|---|---|---|---|
| Unit | t/h | Mpa | Mpa | % | mm | t | |
| WDR0.5-0.8-Ⅱ | 0.5 | 0.8 | 175 | 98.00% | Electric energy | 2540*1880*1845 | 1.28 |
| WDR1.0-1.25-Ⅱ | 1 | 1.25 | 194 | 2810*1895*2250 | 2.29 | ||
| WDR2.0-1.25-Ⅱ | 2 | 3585*2240*2290 | 3.902 | ||||
| WDR4.0-1.25-Ⅱ | 4 | 4585*2600*3595 | 6.51 |
